Application For |
Intel : LGA20XX/LGA1200/1151/1150/1155/LGA1366, AMD : TRX4/TR4/AM4/AM3+/AM3/AM2+/AM2/FM2+/FM2/FM1 |
Radiator Dimensions |
282×120×27 mm |
Radiator Material |
Aluminum |
Net Weight |
1400 g |
Tube length |
380 mm |
Pump Dimensions |
86×75×71 mm |
Pump Speed |
2550 RPM±10% |
Pump Noise |
17.8 dB(A) |
Pump Connector |
3-pin |
Pump Rated Voltage |
12 VDC |
Pump Rated Current |
0.2 A |
Pump Power Consumption |
2.4 W |
Fan Dimensions |
120×120×25 mm |
Fan Speed |
500~1800 RPM±10% |
Fan Airflow |
64.4 CFM |
Fan Air Pressure |
2.33 mmAq |
Fan Noise |
≤32.1 dB(A) |
Fan Connector |
4-pin PWM |
Bearing Type |
Hydro Bearing |
Fan Rated Voltage |
12 VDC |
Fan Rated Current |
0.15 A |
Fan Power Consumption |
1.8 W |
LED Type |
Addressable RGB LED |
LED Connector |
3-pin(+5V-D-G) |
LED Rated Voltage |
5 VDC |
LED Power Consumption |
2.25 W(PUMP) |
