ASUS TUF GAMING B560-PLUS WIFI motherboard - TUF GAMING B560-PLUS WIFI en - No data
- Brand: Asus
- Model No: TUF GAMING B560-PLUS WIFI
- Reward Points: 10
- Availability: In Stock
- Shipping Free
₹15,650
Price in reward points: 10
Learn more about the Asus TUF GAMING B560-PLUS WIFI
Specifiactions –
| Model | ASUS TUF GAMING B560-PLUS WIFI (90MB1740-M0UAY0) |
| CPU Socket | Intel Socket LGA1200 |
| CPU Support | Intel Socket LGA1200 for 11th Gen Intel Core processors & 10th Gen Intel Core |
| Supports Intel 14 nm CPU | |
| Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0 | |
| Chipset | Intel B560 |
| Memory |
DDR4 5000(OC)/4800(OC)/4600(OC)/4400(OC)/4266(OC)/4000(OC)/3733(OC) /3600(OC)/3466(OC)/3333(OC)/3200/2933/2800/2666/2400/2133 MHz Non-ECC, Un-buffered Memory |
| Dual Channel Memory Architecture | |
| Supports Intel Extreme Memory Profile (XMP) | |
| On-Board Graphics support | 1 x DisplayPort 1.4 |
| 1 x HDMI 2.0 | |
| Expansion Slot | Intel 11th & 10th Gen Processors: |
| 1 x PCIe 4.0/3.0 x16 slots | |
| - Intel 11th Core processors support PCIe 4.0 x16 | |
| - Intel 10th processors support PCIe 3.0 x16 | |
| Intel B560 Chipset: | |
| 1 x PCIe 3.0 x16 slot (supports x4 mode) | |
| 3 x PCIe 3.0 x1 slots | |
| Ethernet | 1 x Realtek 2.5Gb Ethernet |
| Wireless and Bluetooth | Intel Wi-Fi 6 |
| 2x2 Wi-Fi 6 (802.11 a/b/g/n/ac/ax) | |
| Supports 2.4/5GHz frequency band | |
| Bluetooth v5.0 or later | |
| Storage | Total supports 2 x M.2 slots and 6 x SATA 6Gb/s ports |
| Intel 11th Gen Processors: | |
| M.2_1 slot (Key M), type 2242/2260/2280/22110 | |
| - Only Intel 11th Core processors support PCIe 4.0 x4 mode, this slot will be disabled for other CPUs | |
| Intel B560 Chipset: | |
| M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 3.0 x4 & SATA modes) | |
| 6 x SATA 6Gb/s ports | |
| Audio | Realtek ALC S1200A 7.1 Surround Sound High Definition Audio CODEC |
| - Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking | |
| - Supports up to 24-Bit/192 kHz playback | |
| Audio Features: | |
| - Audio Shielding | |
| - Rear optical S/PDIF out port | |
| - Premium Japanese audio capacitors | |
| - Dedicated audio PCB layers | |
| Back Panel I/O Ports | 2 x USB 3.2 Gen 2 ports (2 x Type-A) |
| 3 x USB 3.2 Gen 1 ports (2 x Type-A + 1x Type-C) | |
| 3 x USB 2.0 ports (3 x Type-A) | |
| 1 x DisplayPort | |
| 1 x HDMI port | |
| 1 x ASUS Wi-Fi Module | |
| 1 x Realtek 2.5Gb Ethernet port | |
| 5 x Audio jacks | |
| 1 x Optical S/PDIF out port | |
| Internal I/O ports | 1 x Thunderbolt 4 header |
| Fan and Cooling related: | |
| 1 x 4-pin CPU Fan header | |
| 1 x 4-pin CPU OPT Fan header | |
| 1 x 4-pin AIO Pump header | |
| 3 x 4-pin Chassis Fan headers | |
| Power related: | |
| 1 x 24-pin Main Power connector | |
| 1 x 8-pin +12V Power connector | |
| Storage related: | |
| 2 x M.2 slots (Key M) | |
| 6 x SATA 6Gb/s ports | |
| USB: | |
| 1 x USB 3.2 Gen 1 connector (supports USB Type-C) | |
| 1 x USB 3.2 Gen 1 headers support additional 2 USB 3.2 Gen 1 ports | |
| 2 x USB 2.0 headers support additional 4 USB 2.0 ports | |
| Miscellaneous: | |
| 2 x AURA Addressable Gen 2 headers | |
| 2 x AURA RGB headers | |
| 1 x Clear CMOS header | |
| 1 x COM Port header | |
| 1 x Front Panel Audio header (AAFP) | |
| 1 x 20-3 pin System Panel header with Chassis intrude function | |
| 1 x Thunderbolt header | |
| Accessories | Cables: |
| 2 x SATA 6Gb/s cables | |
| Miscellaneous: | |
| 1 x ASUS Wi-Fi moving antennas | |
| 2 x M.2 Rubber Packages | |
| 2 x M.2 SSD screw package | |
| 1 x TUF Gaming sticker | |
| Installation Media: | |
| 1 x Support DVD | |
| Documentation: | |
| 1 x TUF Certification card | |
| 1 x User manual | |
| Dimensions | 30.5 cm x 24.4 cm (12 inch x 9.6 inch ) |
| ATX Form Factor |
WARRANTY
- Limited Warranty period (parts): 3 years
- Limited Warranty period (labor): 3 years
